Hunting For Exportable Android Usage Stats

I am doing some public accountability challenge on instagram and on 15.05.26 the theme was setting goals for improving my time management. I was planning on discussing my problems with AI usage and how much of a time sink my phone was. I needed to show some initial stats based on which comparisons would be made in later updates to show improvement or a lack thereof. I already have a dirty script for checking my AI usage even when its not so understandable. What I did not have at all was access to raw mobile screen time data on my PC.

There's a script I have used before for this purpose and hoped I could reach for it but learnt it was based on a dump format that has since been changed.

So I set out to understand the new format and come up with some script to do the work for me. I ain't a mobile developer and wading through all the dump info was mentally taxing. Decided I'd get some ROI on the task by writing about the process. Its what am going to do in this article.

First, make sure you got adb installed to follow along. Also, make sure your phone supports adb debugging by enabling developer options and doing the needful with the developer settings. I already had adb installed on my system obviously. I'd already connnected my phone and made the first dump with :

adb shell dumpsys usagestats > full_usage_stats.txt

The dump looked like a dump: Martian all over the place if you ain't an android dev, which I am not.

I scrolled down to the section that's got a lot of `package=` style lines. It looked like it had all the data I needed. I couldn't really tell if it didn't. The last dump I made I did not examine the format that closely. Only ran the script on it and it worked fine.

So I decided to list what I needed to keep me from drifting. I needed usage data for a select number of apps. These apps were id'd in the file by their package names. The names had the format `com.appname.something` or `com.appname` for others. Id'ing the apps wasn't the problem. FIguring out what stood for "screen time" is where I had the most challenge.

My tentative task list was like so:

  1. Find out what all fields in each `package=` line means
  2. List all apps we'd need and their corresponding package names.
  3. Extract lines with package names mactching the packages we are intereted in
  4. Extract the metadata from that.
  5. Work on clean presentation
  6. Export to csv for later

Here's a sample package data line.

package=com.instagram.android u=0 bucket=40 reason=f used=+4h18m16s641ms usedByUser=+4h19m28s143ms\
usedScr=+892d14h28m24s823ms lastPred=<uninitialized> expiryTimes=<none>\
lastJob=+52m49s437ms lastInformedBucket=-1 nextEstimatedLaunchTime=+3d7h47m12s335ms idle=y

It's obvious the sample package stats line belongs to instagram. But what in the world does all that extra data mean? We have bucket , reason, used, usedBy, usedScr, lastJob, lastInformedBucket, nextTimeEstimatedLaunch.

To find this out I tried looking at the api ref for the command that produced this info. The `adb dumpsys shell usagestats` ref that is. It interestingly said nothing about the usagestats service. At least nothing I could work with. It did mention each "service" had a detailed help page but the "usagestats" service didn't. Supplying `-h` to dumpsys stats gave the same output as it did when I supplied nothing.

adb shell dumpsys  usagestats --help > output_1.txt
adb shell dumpsys  usagestats > output_2.txt
diff output_1.txt output_2.txt

Tried hunting for the answer from other sources but the few I found all seemed to have been in ref to the old dump format which, I'd learnt was no longer useful. I was so very much trying to avoid using an LLM but this was becoming less of an option and more of an only path.

I copied one of them package lines and posted it as is in my search box. I use Startpage btw. That did not return any results as expected.

So I cut down the search query to only leave the `package=packagename` portion and still got the same results: nothing.

I then searched for 'nextEstimatedLaunchTime`. That's one of the metadata keys in the package line. This led me to the site on some file under the name UsageStatsService.

Turns out its all the java code responsible for the usage stats service. I ain't no JAVA dev and Java is a lot of brain pain but anyways, I was probably going to have to read through this to get what I needed so I did.

There was so much to decipher. I remember when looking at the useless API page I came across an API ref for UsageStats that I didn't pay much attention to as it seemed to have been geared towards app developers. Now that I'd given into an even harder task, reading the api source, I guessed was going to be even easier reading the api.

But before that, I got some more metadat keys from the package line and did a `Ctrl+F` for them from the service source code. Searched for `nextEstimatedLaunchTime`. There was a block of code describing what this did but I still wasn't getting a thing so I googled the term and learnt it had to do with how much time it takes for the app to startup and get fully responsive to user interaction from. More on that here.

Now that ain't of any use to me so I moved on to another data point. There's two that seemed promising. `Used` and `UsedByUsr`. So I started with `Used`. The term is so generic and as thus didn't bring forth anything usable. Got a bunch of ads for used androids mostly. So I switched to the dorks prompt `UsedByUsr android usagestats' That returned nothing.

I then switched using Startpage for a search engine to Google with the same query. That sent me straight to the Android Api for Usage Stats. As research for another personal project, I was recently reading about how search engines work and remember this one part talking about types of browser indexers. It mentioned some did the work of indexing while others dodged it by outsourcing it to those that did. I think this is what Start page does. Its a `metasearch engine`. Anyways. Just a point to note for next time I am choosing what browser to use for research. Actually, reading the wikipedia page on meta search engines I learnt my suspicions were true. See for yourself here.

But back to the topic. I now decided I'd just focus on the UsageStats api after all attempts to dodge it in hope of finding something more straight forward.

I still wasn't understanding a thing so looked at the third result from my search. The third result led me to UsageStatsManager AOSP ref.

This seemed to have been exactly what I needed. The granularity included daily history, weekly history, monthly and annual history intervals. But I had no clue about how I was going to run the Java to extract this data from my phone without having to write a line of JAVA.

So I googled to find more info about this api. That led me to a medium article that pointed to this github repo.

I always hate it when these android folks don't package the apps. But it happens so often that I miss out on ready made solutions. I decided this would be the last time that happened and set out to learn basic android app packaging.

But wait! I need this data in csv format… Why should I bother with app compilation if the only access itll provide will be on mobile? ADB can possibly help out now that I know the words to use for searching right? This led me to searching for how to interface with android UsageStatsManager via ADB.

There was no way to access the data with adb. At least none that I could lay my hands on. All solutions I’d gotten pointed back to the unusable `usagestats` service. I caved in and did some LLM search.

I prompted Deepseek and it didn't get anything I did not already have. The packaging option was now starting to seem like it was my only. I was going to have to learn how to build and compile a simple Java application just so to add csv export functionality and interface with some usagestats api?!

Anyways, I went on to install java and android studio. Something I hope to talk about in another article.

But before that, I tried prompting other LLMs just so in case I'd missed out on an easier solution than building the app myself.

By other LLMs I mean Claude and Gemini. The answers they gave were no different from Deepseek's. They were as well outdated and depended on a usagestats format that no longer was so I moved on with the JAVA project.

Well, a few hours after I'd given up and made plans to learn JAVA android development, I did one last search on Reddit . That's how I got this reddit post talking about StayFree's export option. And, that's how I got all my screen time history from last year on the 9th of November. I went on to turn the data into csv and plan a script to combine that data with data I'm collecting from my browser usage activity.

Since I could not pull any understanable info from the internet on the why for the dumpsys format change, I dumped this article in an LLM prompt box (Gemini's that is, since Gemini I'd believe is more well versed with the AOSP than any other LLM), and kinda figured it out. I linked the conversation in the sources section but in summary: The stats are now meant to tell developers why some app's usage was throttled and the info they convey is more about that: app resource usage management and not screen time reports.

The time I used for all this was 15x more than the time I thought I would and I did not even get to complete the project. I sure do need that public insta accountability it so seems. Classic dev rabbit hole. Anyways. I now have the data. Also, I moved android dev up my todo list and have set up the environment already. Oh, I also got to confirm in action the theory I'd consumed on how search engines work. So I guess there's pluses here and there. Also, notice how confident the LLM’s are with outright false advice and how easy it was to spot it as so since I wasn’t completely dependent on their output.

Thanks for coming this far and as always, I hope you learnt something. See you when in the next one.
